VR-H7 Handheld XRF Analyzer Gun for Gold & Precious Metals

The VR-H7 is a lightweight (1.6kg), handheld XRF analyzer designed for rapid, non-destructive testing of precious metals (Al to U). Featuring a SDD detector and one-button operation, it delivers instant, accurate alloy composition results for jewelry and recycling professionals.

SENT INQUIRY

LIVE CHAT

DOWNLOAD

Specifications

Handheld XRF Precious Metals & Alloy Analyzer

Analyzer Type

4.3-inch Industrial Resistive Touch Screen

Display

1.6 Kg (with battery)

Weight

32GB Internal Memory

Data Storage

254 x 79 x 280 mm

Product Dimensions

USB, Bluetooth

Connectivity

Al to U

Elemental Range

Gravity sensing auto-shutdown, Double-beam sample detection, Radiation protection

Safety Protection

Solids

Sample Types

~8 hours (MSBUS intelligent battery)

Battery Life

50 kV/200 µA X-ray tube (Ag target standard; Au, W, Rh optional)

Excitation Source

-20°C to 50°C

Operating Temperature

SDD Detector

Detector

40% – 70% (Non-condensing)

Operating Humidity

VR-H7 Handheld XRF Analyzer: Professional-Grade Precision in the Palm of Your Hand

The VR-H7 represents the forefront of portable elemental analysis technology, offering laboratory-quality results in a compact, rugged, and user-friendly handheld device. Designed specifically for the fast-paced demands of precious metal verification, alloy sorting, and material identification, this analyzer delivers immediate, non-destructive testing with exceptional accuracy. Weighing just 1.6kg, it combines powerful analytical capabilities with unparalleled portability, making it the ideal tool for on-the-spot analysis in jewelry stores, pawnshops, recycling facilities operations.

At its core, the VR-H7 is equipped with a high-performance X-ray tube (50kV/200µA) and an ultra-high resolution SDD detector, enabling precise analysis of elements from Aluminum (Al) to Uranium (U). Its advanced digital multi-channel processor and optimized algorithm work in concert to achieve lower detection limits and superior spectral resolution, ensuring reliable identification and quantification of alloy compositions and precious metal purity. The innovative “Short Optical Path” design significantly enhances the excitation efficiency for light elements, providing stable performance without the need for vacuum pumps or helium purge systems.

User-centric design is a hallmark of the VR-H7. It features a 4.3-inch industrial resistive touchscreen that remains readable in various lighting conditions, alongside intuitive one-button operation for swift testing. Intelligent systems, including gravity sensing for automatic safety shutdown and double-beam technology for sample presence detection, enhance both operational safety and ease of use. Powered by an MSBUS-compliant intelligent battery, the analyzer supports up to 8 hours of continuous operation and complies with air transport regulations for dangerous goods, ensuring true mobility for field applications. With 32GB of internal memory, USB/Bluetooth connectivity, and robust construction built to withstand harsh environments, the VR-H7 is a versatile, reliable, and powerful solution for anyone requiring definitive material chemistry in an instant.

Rapid Testing

Get results within 30 seconds, greatly improving efficiency.

Versatile Applications

Suitable for a wide range of use cases.

High-Precision Analysis

Advanced algorithms and optical systems ensure accuracy and reliability.

Non-Destructive Testing

Non-contact analysis preserves samples intact.

Core Advantages & Key Features of VR-H7

The VR-H7 Handheld XRF Analyzer delivers professional-grade elemental analysis in a compact, rugged design. Combining speed, accuracy, and exceptional ease of use, it provides instant, non-destructive testing for precious metals and alloys across diverse field applications.

Core Advantages:

Ultra-Portable & Lightweight: Weighing only 1.6kg with an ergonomic gun-style design, it is built for all-day use and effortless handling in any environment.
High Precision Analysis: Equipped with a SDD detector and advanced algorithm for superior resolution and low detection limits, ensuring laboratory-quality results.
Robust Safety Features: Integrated gravity sensing auto-shutdown, double-beam sample detection, and comprehensive radiation protection ensure maximum operational safety.
Extended Field Operation: An intelligent MSBUS battery supports up to 8 hours of continuous testing and complies with air transport regulations for true mobility.
All-Environment Durability: Designed to operate reliably in harsh conditions (-20°C to 50°C) with an industrial-grade resistive touchscreen.

Key Features:

Wide Elemental Range: Precisely analyzes elements from Aluminum (Al) to Uranium (U), ideal for precious metals and alloy verification.
One-Button Operation: Features intuitive one-key testing for fast and accurate results, requiring minimal operator training.
Advanced Hardware: Utilizes a high-performance X-ray tube (50kV/200µA) with optional targets (Ag, Au, W, Rh) for application-specific optimization.
Efficient Data Management: Offers 32GB internal storage with USB and Bluetooth connectivity for seamless data transfer and reporting.
Broad Application Support: Perfect for jewelry authentication, scrap metal recycling, mining exploration, and quality control inspections.
