XRF Gold Tester VR-X3–All-in-One Precious Metal Analyzer

The VR-X3 is a specialized precious metal analyzer offering fast, non-destructive testing for gold and other precious metals. Featuring a built-in industrial computer and multi-point touchscreen, it ensures precise results with active radiation protection, making it ideal for jewelry stores.

SENT INQUIRY

LIVE CHAT

DOWNLOAD

Specifications

AC 100V-240V, 50/60Hz

Input Voltage

φ2.5mm

Collimator Size

590 × 555 × 530 mm

Package Size

0-50 kV / 0-1 mA

HV Power Supply

420 × 400 × 420 mm

Machine Size

≤50dB

Noise Level

320 × 260 × 110 mm

Sample chamber size

0°C to 28°C

Operating Temperature

<150W

Rated Power

<70% (Non-condensing)

Humidity

33 kg (Net) / 45 kg (Gross)

Weight

Au, Ag, Pt, Pd, Ir, Cd, Cu.

Element Analysis Range

Gas Proportional Detector

Detector Type

Multi-point Touch Screen

Display

50 kV / 1 mA

X-ray Tube

USB

Data Transmission

VR-X3 Benchtop Precious Metal Analyzer

The VRAY VR-X3 is a specialized benchtop X-ray fluorescence (XRF) analyzer designed for rapid, non-destructive analysis of precious metals, including gold, silver, platinum, palladium, and other critical elements. Combining robust construction with advanced analytical capabilities, this instrument delivers reliable performance for jewelry stores, pawnshops, recycling facilities, and quality control laboratories. With a focus on ease of use and precision, the VR-X3 features a built-in industrial computer, a multi-point touchscreen interface, and comprehensive safety mechanisms, making it an ideal solution for both technical and non-technical users.

Equipped with a gas proportional detector and a 50kV/1mA X-ray tube, the VR-X3 ensures accurate elemental analysis with a detection sensitivity of up to 10 ppm. Its spacious sample chamber (320 × 260 × 110 mm) accommodates solid samples of various shapes and sizes, while the φ2.5mm collimator enhances measurement precision.

Safety is prioritized through X-ray tube overheating protection, high-voltage safety locks, and automatic radiation cutoff features. The intuitive software interface supports one-click operation, enabling users to obtain results quickly without extensive training. With USB connectivity and real-time data display, the VR-X3 simplifies data export and reporting, streamlining workflows for businesses.

Rapid Testing

Get results within 30 seconds, greatly improving efficiency.

Versatile Applications

Suitable for a wide range of use cases.

High-Precision Analysis

Advanced algorithms and optical systems ensure accuracy and reliability.

Non-Destructive Testing

Non-contact analysis preserves samples intact.

VR-X3: Precision, Portability, and Professional-Grade Performance

The VR-X3 Portable Precious Metal Analyzer delivers fast, non-destructive elemental analysis seven elements, including gold, silver, and copper.

Core Advantages:

Non-Destructive Testing: Accurately analyze the purity of jewelrywithout causing any damage or leaving marks.
Rapid & Precise Results: Achieve reliable results in seconds for key elements (Au, Ag, Pt, Pd, etc.).
Robust Safety Design: Features active radiation protection, an X-ray tube overheating protection system, and high voltage safety safeguards.
All-in-One Portable Design: The built-in industrial computer and multi-point touchscreen eliminate the need for an external laptop.

Key Features:

Advanced Hardware: Equipped with a high-performance X-ray tube (50kV/1mA) and a gas proportional detector.
Intelligent Software: One-key smart testing simplifies operation, while advanced algorithms ensure stability and accuracy by reducing spectrum interference.
Ergonomic Design: Features a clear touchscreen interface for easy on-the-spot testing.
